Ref No
Part Number
Description
Serial Range
Qty
Price

Ref No
1
Part Number
22815-751-700
Description
ARM, CLUTCH
Serial Range
1000001 - 9999999
Qty
Price
$13.00

Ref No
2
Part Number
22817-751-000
Description
HOLDER, CLUTCH WIRE
Serial Range
1000001 - 9999999
Qty
Price
$19.42

Ref No
3
Part Number
24140-763-A02
Description
CABLE B, CLUTCH (BRAKE) (NOT AVAILABLE)
Serial Range
1000001 - 9999999
Qty
Price
$36.72

Ref No
4
Part Number
24147-763-A00
Description
SPRING, CLUTCH
Serial Range
1000001 - 9999999
Qty
Price
$8.20

Ref No
5
Part Number
45423-KA4-700
Description
NUT, HEX. (6MM) (LEFT HAND THREAD)
Serial Range
1000001 - 9999999
Qty
Price
$1.42

Ref No
6
Part Number
46510-763-A00
Description
PEDAL, FOOT BRAKE
Serial Range
1000001 - 9999999
Qty
Price
$47.26

Ref No
7
Part Number
46514-763-A00
Description
SPRING, BRAKE PEDAL
Serial Range
1000001 - 9999999
Qty
Price
$4.00

Ref No
8
Part Number
46515-751-010
Description
BRACKET, BRAKE PEDAL
Serial Range
1000001 - 9999999
Qty
Price
$19.28

Ref No
9
Part Number
46545-751-700
Description
RUBBER, BRAKE PEDAL
Serial Range
1000001 - 9999999
Qty
Price
$12.10

Ref No
10
Part Number
46547-751-000
Description
BUSH, BRAKE ROD
Serial Range
1000001 - 9999999
Qty
Price
$3.86

Ref No
11
Part Number
47241-763-A00
Description
PIPE, BRAKE
Serial Range
1000001 - 9999999
Qty
Price
$37.38

Ref No
12
Part Number
47251-751-000
Description
SPRING, BRAKE ROD SETTING
Serial Range
1000001 - 9999999
Qty
Price
$10.10

Ref No
13
Part Number
47253-763-A00
Description
SHAFT, SPRING SET
Serial Range
1000001 - 9999999
Qty
Price
$19.28

Ref No
14
Part Number
47255-751-000
Description
SPRING, BRAKE DAMPER
Serial Range
1000001 - 9999999
Qty
Price
$5.04

Ref No
15
Part Number
47261-763-D00
Description
ROD A, FOOT BRAKE
Serial Range
1000001 - 9999999
Qty
Price
$23.26

Ref No
16
Part Number
47265-763-A00
Description
ROD B, FOOT BRAKE
Serial Range
1000001 - 9999999
Qty
Price
$4.48

Ref No
17
Part Number
47269-763-A00
Description
PLATE, DAMPER SPRING SETTING
Serial Range
1000001 - 9999999
Qty
Price
$2.70

Ref No
18
Part Number
90015-ZG0-801
Description
BOLT, FLANGE (6X65)
Serial Range
1000001 - 9999999
Qty
Price
$2.58

Ref No
19
Part Number
90104-751-000
Description
BOLT, P.T.O. CLUTCH LEVER
Serial Range
1000001 - 9999999
Qty
Price
$7.24

Ref No
20
Part Number
90118-961-000
Description
NUT, SELF-LOCK (8MM)
Serial Range
1000001 - 9999999
Qty
Price
$4.94

Ref No
21
Part Number
90208-425-870
Description
NUT, FLANGE (8MM) (NOT AVAILABLE)
Serial Range
1000001 - 9999999
Qty
Price
$2.22

Ref No
22
Part Number
90526-751-700
Description
WASHER, BRAKE SPRING SETTING
Serial Range
1000001 - 9999999
Qty
Price
$5.24

Ref No
23
Part Number
90530-751-000
Description
WASHER (6X15)
Serial Range
1000001 - 9999999
Qty
Price
$2.12

Ref No
24
Part Number
90690-GHB-631
Description
CLIP, CABLE (8MM)
Serial Range
1000001 - 9999999
Qty
Price
$1.88

Ref No
25
Part Number
90755-751-010
Description
PIN, CLUTCH JOINT
Serial Range
1000001 - 9999999
Qty
Price
$2.96

Ref No
26
Part Number
92101-05025-0A
Description
BOLT, HEX. (5X25)
Serial Range
1000001 - 9999999
Qty
Price
$1.18

Ref No
27
Part Number
94001-08000-0S
Description
NUT, HEX. (8MM)
Serial Range
1000001 - 9999999
Qty
Price
$1.16

Ref No
28
Part Number
94050-05000
Description
NUT, FLANGE (5MM)
Serial Range
1000001 - 9999999
Qty
Price
$1.16

Ref No
29
Part Number
94101-05800
Description
WASHER, PLAIN (5MM)
Serial Range
1000001 - 9999999
Qty
Price
$0.86

Ref No
30
Part Number
94101-06800
Description
WASHER, PLAIN (6MM)
Serial Range
1000001 - 9999999
Qty
Price
$0.56

Ref No
31
Part Number
94101-08800
Description
WASHER, PLAIN (8MM)
Serial Range
1000001 - 9999999
Qty
Price
$1.78

Ref No
32
Part Number
94201-16120
Description
PIN, SPLIT (1.6X12)
Serial Range
1000001 - 9999999
Qty
Price
$0.90

Ref No
33
Part Number
94201-20150
Description
PIN, SPLIT (2.0X15)
Serial Range
1000001 - 9999999
Qty
Price
$0.90

Ref No
34
Part Number
94305-30282
Description
PIN, SPRING (3X28)
Serial Range
1000001 - 9999999
Qty
Price
$1.38

Ref No
35
Part Number
94305-50282
Description
PIN, SPRING (5X28)
Serial Range
1000001 - 9999999
Qty
Price
$1.52
