Ref No
Part Number
Description
Serial Range
Qty
Price

Ref No
1
Part Number
50613-752-000
Description
ARM, L. RR. LIFT
Serial Range
1000001 - 9999999
Qty
Price
$198.90

Ref No
2
Part Number
50619-752-000
Description
ARM, R. RR. LIFT
Serial Range
1000001 - 9999999
Qty
Price
$198.90

Ref No
3
Part Number
56500-752-020
Description
CYLINDER ASSY., HYDRAULIC (NOT AVAILABLE)
Serial Range
1000001 - 9999999

Ref No
4
Part Number
56510-752-010
Description
CYLINDER, HYDRAULIC
Serial Range
1000001 - 9999999
Qty
Price
$718.30

Ref No
5
Part Number
56521-752-000
Description
PISTON, HYDRAULIC (60MM)
Serial Range
1000001 - 9999999
Qty
Price
$79.26

Ref No
6
Part Number
56531-752-000
Description
ROD, CONNECTING
Serial Range
1000001 - 9999999
Qty
Price
$34.74

Ref No
7
Part Number
56532-752-000
Description
PIN, CONNECTING ROD
Serial Range
1000001 - 9999999
Qty
Price
$9.72

Ref No
8
Part Number
56533-752-020
Description
ARM, HYDRAULIC CYLINDER
Serial Range
1000001 - 9999999
Qty
Price
$102.18

Ref No
9
Part Number
56537-752-000
Description
SHAFT, HYDRAULIC CYLINDER
Serial Range
1000001 - 9999999
Qty
Price
$167.26

Ref No
10
Part Number
56538-752-010
Description
PLATE, CONNECTING ROD PIN
Serial Range
1000001 - 9999999
Qty
Price
$4.84

Ref No
11
Part Number
56541-752-000
Description
SHAFT, STOPPER
Serial Range
1000001 - 9999999
Qty
Price
$33.44

Ref No
12
Part Number
56546-752-000
Description
COVER, CYLINDER
Serial Range
1000001 - 9999999
Qty
Price
$48.24

Ref No
13
Part Number
56547-769-750
Description
GASKET, HYDRAULIC CYLINDER COVER (NOT AVAILABLE)
Serial Range
1000001 - 9999999
Qty
Price
$14.12

Ref No
14
Part Number
90405-463-000
Description
WASHER (8MM)
Serial Range
1000001 - 9999999
Qty
Price
$3.50

Ref No
15
Part Number
90411-744-000
Description
WASHER, CONICAL SPRING (6MM)
Serial Range
1000001 - 9999999
Qty
Price
$3.70

Ref No
16
Part Number
90445-752-000
Description
WASHER, THRUST (25.5X50X5)
Serial Range
1000001 - 9999999
Qty
Price
$10.48

Ref No
17
Part Number
90505-752-000
Description
WASHER, PLAIN (INNER) (28.5MM)
Serial Range
1000001 - 9999999
Qty
Price
$7.24

Ref No
18
Part Number
90506-752-000
Description
WASHER, PLAIN (INNER) (25.5MM)
Serial Range
1000001 - 9999999
Qty
Price
$7.24

Ref No
19
Part Number
90507-752-000
Description
WASHER, PLAIN (OUTER) (30.5MM)
Serial Range
1000001 - 9999999
Qty
Price
$6.50

Ref No
20
Part Number
90508-752-000
Description
WASHER, PLAIN (OUTER) (25.5MM)
Serial Range
1000001 - 9999999
Qty
Price
$6.50

Ref No
21
Part Number
91251-752-000
Description
OIL SEAL (30X44X8)
Serial Range
1000001 - 9999999
Qty
Price
$7.36

Ref No
22
Part Number
91252-752-000
Description
OIL SEAL (25X38X9)
Serial Range
1000001 - 9999999
Qty
Price
$7.36

Ref No
23
Part Number
91351-752-003
Description
O-RING, HYDRAULIC CYLINDER
Serial Range
1000001 - 9999999
Qty
Price
$4.14

Ref No
24
Part Number
91361-752-000
Description
O-RING (17X3.5)
Serial Range
1000001 - 9999999
Qty
Price
$3.16

Ref No
25
Part Number
91311-PH7-003
Description
O-RING (13.8X2.4) (NOK)
Serial Range
1000001 - 9999999
Qty
Price
$2.28

Ref No
26
Part Number
91391-752-003
Description
RING, BACK-UP
Serial Range
1000001 - 9999999
Qty
Price
$9.48

Ref No
27
Part Number
91410-752-000
Description
RING, STOPPER (49)
Serial Range
1000001 - 9999999
Qty
Price
$5.98

Ref No
28
Part Number
91411-752-000
Description
RING, STOPPER (43)
Serial Range
1000001 - 9999999
Qty
Price
$5.98

Ref No
29
Part Number
92101-06012-0A
Description
BOLT, HEX. (6X12)
Serial Range
1000001 - 9999999
Qty
Price
$1.34

Ref No
30
Part Number
92101-08022-0H
Description
BOLT, HEX. (8X22)
Serial Range
1000001 - 9999999
Qty
Price
$1.60

Ref No
31
Part Number
92800-14000
Description
BOLT, DRAIN PLUG (14MM)
Serial Range
1000001 - 9999999
Qty
Price
$4.10

Ref No
32
Part Number
94109-14000
Description
WASHER, DRAIN PLUG (14MM)
Serial Range
1000001 - 9999999
Qty
Price
$0.64

Ref No
33
Part Number
94305-60402
Description
PIN, SPRING (6X40)
Serial Range
1000001 - 9999999
Qty
Price
$1.90

Ref No
34
Part Number
95701-10040-08
Description
BOLT, FLANGE (10X40)
Serial Range
1000001 - 9999999
Qty
Price
$2.16

Ref No
35
Part Number
95701-10055-08
Description
BOLT, FLANGE (10X55)
Serial Range
1000001 - 9999999
Qty
Price
$2.60

Ref No
36
Part Number
95701-12050-08
Description
BOLT, FLANGE (12X50)
Serial Range
1000001 - 9999999
Qty
Price
$3.06
