Ref No
Part Number
Description
Serial Range
Qty
Price

Ref No
1
Part Number
30566-895-000
Description
CLAMP C, CABLE
Serial Range
1000001 - 9999999
Qty
Price
$3.14

Ref No
2
Part Number
30585-Z03-C02
Description
IGNITION UNIT
Serial Range
1000001 - 9999999
Qty
Price
$63.61

Ref No
3
Part Number
31460-ZS9-A01
Description
RECEPTACLE, D.C.
Serial Range
1000001 - 9999999
Qty
Price
$50.88

Ref No
4
Part Number
31710-ZS9-A02
Description
RECTIFIER ASSY.
Serial Range
1000001 - 9999999
Qty
Price
$17.56

Ref No
5
Part Number
32100-Z03-C32
Description
WIRE HARNESS ASSY., MAIN
Serial Range
1000001 - 9999999
Qty
Price
$54.78

Ref No
6
Part Number
32105-Z04-E31
Description
SUB-WIRE HARNESS ASSY.
Serial Range
1000001 - 9999999
Qty
Price
$47.76

Ref No
7
Part Number
32196-Z04-E31
Description
SUB-WIRE ASSY.
Serial Range
1000001 - 9999999
Qty
Price
$46.68

Ref No
8
Part Number
32330-Z03-C31
Description
RECEPTACLE (20A/125V)
Serial Range
1000001 - 9999999
Qty
Price
$35.62

Ref No
9
Part Number
32332-Z04-C31
Description
RECEPTACLE (30A/125V)
Serial Range
1000001 - 9999999
Qty
Price
$39.70

Ref No
10
Part Number
32340-Z04-D31
Description
BOX ASSY., CONTROL
Serial Range
1000001 - 1004588
Qty
Price
$417.24

Ref No
10
Part Number
32340-Z04-D32
Description
BOX ASSY., CONTROL
Serial Range
1004589 - 9999999
Qty
Price
$417.24

Ref No
11
Part Number
32345-Z03-C31
Description
PANEL, CONTROL
Serial Range
1004589 - 9999999
Qty
Price
$101.52

Ref No
12
Part Number
32356-Z03-S10
Description
CASE, CONTROL (C1)
Serial Range
1000001 - 9999999
Qty
Price
$56.52

Ref No
13
Part Number
32366-Z04-D30
Description
MARK, CONTROL PANEL
Serial Range
1000001 - 9999999
Qty
Price
$80.70

Ref No
14
Part Number
35120-Z11-E01
Description
SWITCH ASSY., ENGINE STOP (RED)
Serial Range
1000001 - 9999999
Qty
Price
$13.28

Ref No
15
Part Number
38220-ZT0-K31
Description
BREAKER, CIRCUIT (22A)
Serial Range
1000001 - 9999999
Qty
Price
$41.84

Ref No
16
Part Number
38240-ZC2-E30
Description
PROTECTOR, CIRCUIT (20A)
Serial Range
1000001 - 1004588
Qty
Price
$67.50

Ref No
16
Part Number
38240-ZC2-E31
Description
PROTECTOR, CIRCUIT (20A)
Serial Range
1004589 - 9999999
Qty
Price
$67.50

Ref No
17
Part Number
63268-Z03-000
Description
INSULATOR (A)
Serial Range
1004589 - 9999999
Qty
Price
$8.86

Ref No
18
Part Number
63269-Z03-000
Description
INSULATOR (B)
Serial Range
1000001 - 9999999
Qty
Price
$11.64

Ref No
19
Part Number
63270-Z03-000
Description
INSULATOR (C)
Serial Range
1000001 - 9999999
Qty
Price
$2.32

Ref No
20
Part Number
63271-Z03-020
Description
INSULATOR (D)
Serial Range
1000001 - 9999999
Qty
Price
$3.48

Ref No
21
Part Number
90013-883-000
Description
BOLT, FLANGE (6X12) (CT200)
Serial Range
1000001 - 9999999
Qty
Price
$1.38

Ref No
22
Part Number
90108-MN0-000
Description
SCREW, PAN (5X13)
Serial Range
1000001 - 9999999
Qty
Price
$1.50

Ref No
23
Part Number
90301-Z03-000
Description
NUT, WELL (6MM)
Serial Range
1000001 - 9999999
Qty
Price
$1.88

Ref No
25
Part Number
90691-ZB7-003
Description
CLIP, HARNESS
Serial Range
1000001 - 9999999
Qty
Price
$2.90

Ref No
26
Part Number
91651-ZD8-K61
Description
GROMMET, WIRE HARNESS
Serial Range
1000001 - 9999999
Qty
Price
$3.86

Ref No
27
Part Number
92101-06022-0A
Description
BOLT, HEX. (6X22)
Serial Range
1000001 - 9999999
Qty
Price
$1.38

Ref No
28
Part Number
93500-03005-1G
Description
SCREW, PAN (3X5)
Serial Range
1000001 - 9999999
Qty
Price
$0.60

Ref No
29
Part Number
93500-03008-0H
Description
SCREW, PAN (3X8)
Serial Range
1000001 - 9999999
Qty
Price
$0.64

Ref No
30
Part Number
93500-04010-0H
Description
SCREW, PAN (4X10)
Serial Range
1000001 - 9999999
Qty
Price
$0.80

Ref No
31
Part Number
93893-04008-00
Description
SCREW-WASHER (4X8)
Serial Range
1000001 - 9999999
Qty
Price
$1.20

Ref No
32
Part Number
93911-25180
Description
SCREW, TAPPING (5X10)
Serial Range
1000001 - 9999999
Qty
Price
$0.44

Ref No
33
Part Number
93913-25210
Description
SCREW, TAPPING (5X12)
Serial Range
1000001 - 9999999
Qty
Price
$0.42

Ref No
34
Part Number
94001-06390-0S
Description
NUT, HEX. (6MM)
Serial Range
1000001 - 9999999
Qty
Price
$1.38

Ref No
35
Part Number
94050-04080
Description
NUT, FLANGE (4MM)
Serial Range
1000001 - 9999999
Qty
Price
$1.14

Ref No
36
Part Number
94101-06800
Description
WASHER, PLAIN (6MM)
Serial Range
1000001 - 9999999
Qty
Price
$0.56

Ref No
37
Part Number
94111-06800
Description
WASHER, SPRING (6MM)
Serial Range
1000001 - 9999999
Qty
Price
$1.00

Ref No
38
Part Number
95701-06012-00
Description
BOLT, FLANGE (6X12)
Serial Range
1000001 - 9999999
Qty
Price
$1.42

Ref No
39
Part Number
95701-06020-00
Description
BOLT, FLANGE (6X20)
Serial Range
1000001 - 9999999
Qty
Price
$1.42

Ref No
40
Part Number
31428-Z03-C00
Description
TERMINAL SET, GROUND
Serial Range
1000001 - 9999999
Qty
Price
$3.72
